PPE

ATRAX 11,6 MM

REF. 1781

EN 1891 type A

Semi-static double-braided 100% polyester rope with very high dimensional stability over time and which remains flexible and fluid with use.

CE EN 1891 Certified.

Splice upon request.

Advantages :

No «sock effect».
Diameter does not increase with water.
New patented splice specially developed for application with mechanicals Prusik and cams*. (see Rope feed).
This rope runs smoothly and its lifespan is exceptional.

5 m to 60 m units or long lengths.

TECHNICAL DOCUMENTATION

EU DECLARATION Semi static rope Atrax 11.6-Ref.1781

Find a Tree Work seller

Diameter11.6

Weight102 g/m

Knotability1.03

Shrinkage in water0.5 %

Number of strands24

Number of falls8

Diameter under 10 kg11.6 mm

Mass per meter without load103.2 g/m

Mass per meter under 10 kg102 g/m

Number of falls>5

Impact force0.52 kN

Static elongation from 50 to 150 kg2.8 %

Breaking strength30.7 kN

Breaking strength on 8 knot≥ 1,5 kN

Percentage of core45 %

Percentage of sheath55 %

Knotability1.03

Shrinkage in water0.5 %

Sheath slippage0 %

Core number of plaits12 braided plaits

Sheath number of plaits24 braided plaits

Material100 % polyester
